Thank you swagatam I hope you can get it right where I've failed. I know nothing about to try get the 2.4 volts at near 40 milliamps so ill include one here can you modify the circuit to deliver 2.4 volts dc at near 40 milliamps for me and powered from a nine volts battery. so the best way to go is may be to modify an already existing laser power supply for a laser diode I wanted 40 milliamps or to be safe just under it so I used the lm317 current regulator calculator and the resistor I entered got me 40 milliampsīut when I bread boarded it I got no where near it. I breadboarded it only to find out the voltage output was no where near the output of 2.4 volts I wanted, despite what the lm317 regulator calculator says so I used an lm317 regulator calculator for voltage and So trying to find a simple lm317 regulator circuit that will deliver 2.4 volts dc at up to or near 40 milliamps is hard. Now I've looked all over the net for a power supply circuit using the lm317 regulator for this diode but there's circuits for other diodes only but there voltage and currents are different I brought some 10 milliwats laser diodes from xxxx electronics here, the data on them isn't much but maybe enough to go by, they are 2.4 volts and the threshold current is 24 milliamps and the maximum current is 40 milliamps

I'm emailing you to ask you for your expertise, and you being one of India's finest electronics engineers I thought you be the best man in the world to know, bear with me my friend its a bit of a long story.
